Supermarket Heavy Duty Storage Racks With Adjustable 50mm 75mm 76.2mm Pitch

Brand Name : Lijin

Model Number : HD65878

Certification : IS9001;AS4084

Place of Origin : China

MOQ : 5

Price : Factory Price

Payment Terms : T/T, L/C

Supply Ability : 3000 sets / months

Delivery Time : 15 days

Packaging Details : bubble film

Layer : Up to your requirement

Loading Capacity : ≤8000kg per level or Customized

Depth : 1.5-3.0MM

Type : Boltless / Rivet Shelving

Components : Upright Frame + Beam

Application : Storage and Display Rack

Scale : Heavy Duty pallet rack

Surface treatment : High Grade Cold-rolled Steel

Contact Now

High Quality Industrial Heavy Duty Metal Pallet Stack Storage Rack With Adjustable 50mm&75mm&76.2mm Pitch
Product Description

1). Pallet racking is also called beam pallet racking which is of cut-in composite structure; the upright made by continuous punching and rolling; the frame is assembled by upright,bracing and beams are fixed to uprights by hooks.

2). There are safety locks fix beams and uprights tightly, protecting beams from dropping when loading goods with forklifts.

3). The height of each layer can be adjusted by 50mm, 75mm or 76.2mm freely, the capacity of each layer can be up to 4000kg.

4). It's convenient to load and unload pallets with goods on by using forklifts; Such as front-move forklift ,balance-weight forklift and common forklift can be used to load and unload goods.

5). Steel panels, wooden panels and decking are also available for putting on beams instead of pallets.

6). Pallet racking is the most common storage system which is used in fields of manufacturing industry,the third part logistics,distribution centers,supermarket and so on.

Detalied Photes

Product Parameters


- Upright Profile
Upright profiles in different sizes, with both Straight Flange and Returned Flange, are rollformed from high quality steel coils to cater for
wide range of frame load requirements. Hole patterns with Pitch Height 50mm, 75mm, and 76.2mm (3") are available.
Surface Finish:
- Pre-Galvanised (Pregal), or
- Powder coated RAL 5015

- Footplate

- Box Beam and Beam Connector
A wide range of Box Beam sizes are available with customized lengths to meet varied pallet sizes and load rating requirements. Several types of beam connector/bracket brand as shown in the table below are also available to meet different market needs.
